DCI202K
FEATURES
- Type：Character
- Display format: 20×2 CharacterCOG
- Controller IC: ST7036i(or equivalent)
- Duty cycle: 1/16
- 5×8 dots includes cursor
- +3.3V power supply
- LED can be driven by in pinA,pinK
- PDF DOWNLOAD
- Description
- Inquiry
This Chip-On-Glass (COG) 20×2 character Liquid Crystal Display shows characters with dark pixels on a white background. The FSTN positive display can achieve higher contrast and is visible with ambient light or the built-in backlight. As a COG display, there’s no PCB, and the controller/driver is directly bonded to the glass of the display. The operating temperature range is from -20 to 70 degrees Celsius and the supply voltage is 3.3V. Compatible with popular development boards, such as Arduino.
