DCP81C
FEATURES
- Type：Character
- Display format: 8x1Character
- Controller IC: ST7066U(or equivalent)
- Duty cycle: 1/8
- 5×8 dots includes cursor
- +5.0V power supply (also available for +3.3V)
- Specifications
- 3D Render
- Description
- Inquiry
Display Zone 8×1 character Liquid Crystal Display shows characters with dark pixels on a gray background. This reflective LCD Display is visible with high ambient light and despite not having a backlight, the visibility of the display is uncompromised, maximizing efficiency without consuming unnecessary power. Designed for robust performance, this single line, eight chartacter display operates effectively across a broad temperature range of -20 to 70 degrees Celsius, making it ideal for a multitude of environments. DCP81C-RN-GBW model is thoughtfully designed to deliver optimal viewing at a 6:00 angle, ensuring user-friendly readability from various positions. This display operates at 3.3V/5.0V supply voltage, its compatible with arduino and other development boards, has a built-in ST7066U controller and is RoHS compliant.
